AMOLED 모듈

저전력 고시인성 컬러 OLED

AMOLED 모듈은 각 픽셀이 스스로 빛을 내는 자발광 방식으로 명암비가 뛰어나고 색 재현력이 우수하며, 전력 소모가 적어 스마트폰, 웨어러블, 의료용등 다양한 기기에 활용됩니다

contact
AMOLED 모듈

AMOLED 모듈

AMOLED 모듈 (Active Matrix Organic Light Emitting Diode)은 자체 발광 유기물질을 사용하여 백라이트 없이도 선명한 색상과 높은 명암비를 구현하는 디스플레이 기술이며 다양한 인터페이스 방식 지원 및 소형부터 중형 사이즈까지는 물론 원형, 플렉시블 등 다양한 형태로 제공 됩니다. AMOLED 모듈 은 모바일, 웨어러블 기기, 산업용 장비, 의료기기 등 다양한 분야에서 폭넓게 활용되고 있으며, 고화질과 저전력, 슬림한 디자인을 동시에 실현합니다                                                                                                                                                                                          -원하시는 사양을 알려 주시면 제품을 선정해 드립니다-

SizeModel NameShapeResolutionColorBondingDriver ICInterfacePins
0.95"A010XVHMEK01TFlat120×24016.7MRM69310 + ZTW523BSPI30pins
1.1"A010XVHMEK10TFlat126×29416.7MSPI
1.2"A012XDHPEK01TFlat Circular390×39016.7MCOGRM67162MIPI.SPI30pins
1.2"A012XYHMEK05TFlat Circular390×39016.7MMIPI.SPI
1.2"H120BLN0EK2.0Flat Circular390×39016.7MCOGW022 ASICMIPI.SPI20pins
1.2"A012XVHMEK01TFlat Circular390×39016.7MMIPI.SPI
1.2"X120BLNEK02Flat Circular390×39016.7MCOGW022 ASICMIPI.SPI24pins
1.2"H120BLX0EK1.0Flat Circular390×39016.7MCOGWT010MIPI.SPI30pins
1.2"A012XVHMEK05-00TFlat Circular390×39016.7MICNA3311MIPI.SPI34pins
1.2"X120BLNEK01Flat Circular390×39016.7MCOGW022 ASICMIPI.SPI24pins
1.2"H120BLN0EK1.7Flat Circular390×39016.7MCOGW022 ASICMIPI.SPI24pins
1.28"U128BLA0EK3.0Flat Circular416×41616.7MWT030MIPI.SPI30pins
1.3"A013XDHPEK01TFlat Circular360×36016.7MCOGRM69330MIPI.SPI30pins
1.3"H130BLK0EK1.0Flat240×24016.7MCOGW040MIPI.SPI45pins
1.3"H130BLK0EK1.1Flat240×24016.7MCOGW040MIPI.SPI40pins
1.32"A013XVHMEK20TFlat Circular466×46616.7MMIPI.SPI
1.39"H139BLN0EK1.0Flat Circular400×40016.7MCOFRM69080MIPI.SPI24pins
1.39"H139BLN0EK1.1Flat Circular400×40016.7MCOFRM69080MIPI.SPI24pins
1.39"H139BLN0EK1.2Flat Circular400×40016.7MCOFRM69080MIPI.SPI20pins
1.39"H139CLN0EK2.0Flat Circular454×45416.7MMIPI.SPI20pins
1.39"X139BLB0EK1.0Flat Circular400×40016.7MMIPI.SPI24pins
1.4"A014XDHNEK01TFlat Circular300×30016.7MMIPI.SPI
1.4"A014XVHMEK50TFlat320×36016.7MMIPI.SPI
1.4"U141QLX0EK1.0Flat320×36016.7MCOGWT010MIPI.SPI30pins
1.4"U141QLX0EK3.1Flat320×36016.7MMIPI.SPI
1.4"U141QLX0EK1.1Flat320×36016.7MCOGWT010MIPI.SPI30pins
1.43"A014XVHMEK1TFlat Circular466×46616.7MMIPI.SPI
1.45"H145ALN0EK1.0Flat280×28016.7MMIPI.SPI20pins
1.5"A015XVHMEK03-00TFlat194×36816.7MCOGSH801BMIPI.SPI31pins
1.5"A015XVHMEK01Flat194×36816.7MMIPI.SPI
1.54"A015XVHFEK0Flat188×46016.7MMIPI.SPI
1.6"A016XVHNEK05Flat152×48616.7MRM69091, RM69092MIPI.SPI31pins
1.6"A016XVHMEK05Flat152×48616.7MMIPI.SPI
1.63"H163QLNEK01.1Flat320×32016.7MCOGRM69032MIPI.SPI20pins
1.63"H163QLNEK01.0Flat320×32016.7MCOGRM69032MIPI.SPI20pins
1.63"X163QLNEK01Flat320×32016.7MCOGRM69032MIPI.SPI20pins
1.64"A016XVHMEK01Flat280×45616.7MMIPI.SPI
1.7"A017XVHMEK20Flat336×48016.7MMIPI.SPI
1.74"A017XVHMEK01Flat390×45016.7MMIPI.SPI
2.0"H020HDEK01 V0Flat176×22065K/262KuPD161621 MIPI.SPI34pins
3.5"U349QLNEK01.0Flat1440×160016.7MCOGS6E3HA3MIPI.SPI61pins
3.8"H381DLNEK01.2Flat1080×120016.7MCOGRM69071MIPI.SPI39pins
3.8"H381DLNEK01.0Flat1080×120016.7MCOGRM69071MIPI.SPI39pins
4.3"H429ALNEK01 V0Flat540×96016.7MRM69032MIPI.SPI
4.8"H477ULNEK01.1Flat1792×224016.7MMIPI.SPI60pins
4.9"A049VGHMEK01Flat1080×192016.7MCOGRM67198G99MIPI.SPI
4.9"A049VHHMEK01Flat1080×192016.7MMIPI.SPI
5"H497TLBEK01.0Flat720×128016.7MRM69052MIPI.SPI39pins
5"H497TLBEK01.4Flat720×128016.7MRM69052MIPI.SPI39pins
5"H499TLBEK01 V0Flat720×128016.7MRM69052MIPI.SPI39pins
5"H497TLBEK01Flat720×128016.7MRM69052MIPI.SPI
5"H500TLBEK01.0Flat720×128016.7MRM69052MIPI.SPI39pins
5"H497TLBEK01.0 CELLFlat720×128016.7MCOGRM69052MIPI.SPI
5.1"H515DLKEK01.0Flat1080×192016.7MMIPI.SPI40pins
5.2"H520DLKEK01.0Flat1080×192016.7MCOGM031MIPI.SPI
5.5"A055VGHMEK01-02Flat1080×192016.7MCOGRM67198G98MIPI.SPI
5.5"A055JVHMEK03Flat720×128016.7MCOGRM67120G90MIPI.SPI40pins
5.5"H546DLBEK01.1Flat1080×192016.7MCOGRM69070MIPI.SPI40pins
5.5"A055JHHMEK01Flat720×128016.7MCOGRM67120G90MIPI.SPI
5.5"A055VDHMEK05Flat1080×192016.7MCOGAXG840044FE1MIPI.SPI40pins
5.5"A055JVHMEK02Flat720×128016.7MCOGRM67120G90MIPI.SPI40pins
5.5"A055VGWMEK01-02Flat1080×192016.7MCOGRM67198G98MIPI.SPI
5.5"A055VGHMEK01-05Flat1080×192016.7MCOGRM67198G98MIPI.SPI
5.5"X546DLTEK01Flat1080×192016.7MMIPI.SPI40pins
5.5"X546DLBEK01.0Flat1080×192016.7MMIPI.SPI40pins
5.5"H546DLBEK01.2Flat1080×192016.7MMIPI.SPI40pins
5.5"H546DLKEK01.0Flat1080×192016.7MCOGRM69071MIPI.SPI
5.9"A059XXWFEK01Flat1125×243616.7MRM69351MIPI.SPI39pins
6"A060VGHMEK01-00Flat1080×216016.7MCOGRM69299 F93MIPI.SPI
6"A060VVHMEK01Flat1080×216016.7MCOGRM69299, R66455, MIPI.SPI50pins
6"A060VGHMEK01-08Flat1080×216016.7MCOGRM69299MIPI.SPI
6"A060VVWMEK08-01Flat1080×216016.7MCOGR66455MIPI.SPI40pins
6"A060VDHMEK01Flat1080×216016.7MMIPI.SPI
6"A060JYHMEK01-00Flat780×168816.7MMIPI.SPI
6.2"A062VGHXEK01Flat1080×224816.7MCOFRM69299MIPI.SPI
6.3"A064VGWXEK02Flat1080×234016.7MCOFNT37700FMIPI.SPI
6.3"A064VGWXEK01Flat1080×234016.7MCOFNT37700FMIPI.SPI
6.3"A064VGWXEK01-02Flat1080×234016.7MCOFR66455MIPI.SPI
6.5"A066FVWKEK02Flat1080×240016.7MMIPI.SPI
6.5"A066VYWKEK01-00Flat1080×240016.7MMIPI.SPI
6.6"A066FJMKEK01-00Flat1080×2400COGVTDR6115MIPI.SPI
6.6"A066FVWXEK01Flat16.7MMIPI.SPI
6.7"A067FVMKEK01-08Flat1080×240016.7MCOGRM692E5, NT37701AMIPI.SPI
6.7"A067XJMKEK05-05Flat1200×2664COGRM692E5MIPI.SPI
6.7"A067XJWKEK02-08Flat1236×2676COGNT37701HMIPI.SPI
6.8"A068XJWKEK01-00Flat1200×265216.7MCOGILI783AMIPI.SPI
6.8"A068XVWKEK02-00Flat1200×265216.7MCOGNT37701AH/A/HMIPI.SPI
6.8"A068FJWKEK03-00Flat1080×240016.7MCOGNT37705MIPI.SPI
7"A070FFHMEK01-00Flat1080×192016.7MCOGICNA3520MIPI.SPI39pins
